AK APPLE RED & WHITE
SUMMARY
SPECIALITIES
TECHNICAL INFORMATION
SIZE
AK APPLE RED &WHITE
SPECIALITIES
State-of-the-art ideas for home and commercial purposes; engineered to deliver the perfect amalgamation of design, durability and performance
| NO | TESTS REPORTS | PRESCRIBED VALUE | VALUE OBTAINED |
| 1 |
Dimensions,mm a) Length b) Width |
+6mm, -0mm +3mm, -0mm |
+2 +1 |
| 2 | Squareness, % | Max. 0.2 | 0.04 |
| 3 | Edge straightness, % | Max. 0.2 | 0.05 |
| 4 | Workmanship and Finish | As per clause 7 | Conforms |
| 5 | Moisture Content % | 5-15 | 10.5 |
| 6 | Glue adhesion strength in dry state i) Glue adhesion strength, N a) Average b) Min. Individual ii) ) Adhesion of plies.(Knife test) |
1350 1100 Min.Pass standard |
1410 1390 Excellent |
| 7 | Water resistance test (After 72 hrs. boiling), N i) Glue adhesion strength, N a) Average b) Min. Individual ii) Adhesion of plies.(Knife test) |
1000 800 Min.Pass standard |
1090 1050 Excellent |
| 8 | Tensile strength, N/mm2 i) Parallel to the face grain ii) Perpendicular to face grain iii) Sum of the tensile strength |
Min. 42.0 Min. 25.0 Min. 84.50 |
48 37 85 |
| 9 | Mycological test i) Glue adhesion strength, N a) Average b) Min. Individual ii) Adhesion of plies.(Knife test) |
1000 800 Min.Pass standard |
1090 1050 Excellent |
| 10 | Static bending strength Modulus of Elasticity, N/mm2 i) Along the face grain a) Average b) Min. Individual ii) Across the face grain a) Average b) Min. Individual |
7500
4000 |
7790
6421 |
| 11 | Modulus of Rupture Modulus of Elasticity, N/mm2 i) Along the face grain a) Average b) Min. Individual ii) Across the face grain a) Average b) Min. Individual |
50
30 |
57
44 |
| 12 | Wet bending strength, Modulus of Elasticity, N/mm2 i) Along the face grain a) Average b) Min. Individual ii) Across the face grain a) Average b) Min. Individual |
3750
2000 |
4785
3850 |
| 13 | Modulus of Rupture Modulus of Elasticity, N/mm2 i) Along the face grain a) Average b) Min. Individual ii) Across the face grain a) Average b) Min. Individual |
25
15 |
33
27 |
| 14 | Retention of Preservative chemicals, Kg/m3 | Min.12 | 12.510 |
COMMON THICKNESS RANGE
4mm to 25mm
COMMON SIZE
8feet x 4feet, 7feet x 4feet, 6feet x 4feet, 8feet x 3feet, 7feet x 3feet, 6feet x 3feet, 5feet x 4feet, 5feet x 3feet and other sizes as per customer requirement.
BOND/ADHESIVE
BWP grade resin as per IS 848.
Low formaldehyde formulation for compliance to emission level requirements such as E1.
STANDARD
Conforms to IS 710 (BWP grade)
WARRANTY
15 years warranty
