MR GRADE
AK HIT PLY/APPLE VILLA
AK ALTRA PLY/ APPLE ALTRA
AK ALTRA PLY / APPLE ALTRA
This material is produced as per double pressing technology which includes calibration and re sanding in imported machinery.
SUMMARY
SPECIALITIES
TECHNICAL INFORMATION
SIZE
AK ALTRA PLY/APPLE ALTRA
SPECIALITIES
State-of-the-art ideas for home and commercial purposes; engineered to deliver the perfect amalgamation of design, durability and performance.
TECHNICAL INFORMATION AS PER 308:1989
NOTESTSPRECRIBED VALUEVALUE OBTAINED1Dimensions, mm
a) Length
b) Width
c) ThicknessTolerance +6mm -0mm
Tolerance +3mm -0mm
+/-5%+2mm
+1mm
+2%
| 2 | Squareness, % | 0.2 | 0.05 |
| 3 | Edge straightness, % | 0.2 | 0.06 |
| 4 | Workmanship and Finish | Conforms | Conforms |
| 5 | Moisture Content % | 5-15 | 10 |
| 6 | Resistance to water, Adhesion of plies | Min. Pass standard | Pass standard |
| 7 | Resistance to micro organisms ( Adhesion of plies) |
Min. Pass standard | Excellent |
| 8 | Modulus of Elasticity, N/mm2 i) Parallel to the face grain a) Average b) Min. Individual ii) Perpendicular to the Face grain a) Average b) Min. Individual |
4000 36002000 1800 |
5420 50204560 4120 |
| 9 | Modulus of Rupture, N/mm2 i) Parallel to the face grain a) Average b) Min. Individual ii) Perpendicular to the Face grain |
30 2715 13 |
50 4640 34 |
COMMON THICKNESS RANGE
4mm to 25mm
COMMON SIZE
8feet x 4feet, 7feet x 4feet, 6feet x 4feet, 8feet x 3feet, 7feet x 3feet, 6feet x 3feet, 5feet x 4feet, 5feet x 3feet and other sizes as per customer requirement
BOND/ADHESIVE
MR grade resin as per IS 848.
Low formaldehyde formulation for compliance to emission level requirements such as E1.
STANDARD
Conforms to IS 303 (MR grade)
WARRANTY
5 years
