AK / APPLE PLATINUM PLUS - Apple Plywoods

BWP GRADE

AK Apple Platinum Plus+ is the most premium in the product range which has full gurjan stitched long panel core bonded with phenol formaldehyde resin and manufactured as per IS 710 standards. AK Apple Platinum Plus+ has been industrially vacuum pressure treated with approved preservatives to make it borer proof and comes with life time 700% money back warranty.

The core composed in an automatic core composer machine which makes 8’x4’ sheets and this material is produced as per double pressing technology which includes calibration and re sanding in well advanced heavy-duty top and bottom calibration imported machinery. AK Apple Platinum Plus+ ply is very suitable for Acrylic laminates.

SUMMARY

SPECIALITIES

TECHNICAL INFORMATION

SIZE

AK APPLE PLATINUM PLUS +

SPECIALITIES

State-of-the-art ideas for home and commercial purposes; engineered to deliver the perfect amalgamation of design, durability and performance

NO	TESTS	PRESCRIBED VALUE	VALUE OBTAINED
1	Dimensions, mm a) Length b) Width	Tolerance +6mm -0mm Tolerance +3mm -0mm	+2mm +1mm
2	Squareness, %	0.2	0.04
3	Edge straightness, %	0.2	0.05
4	Workmanship and Finish	Conforms	Conforms
5	Moisture Content %	5-15	10.2
6	Glue adhesion strength in dry state i) Glue adhesion strength, N a) Average b) Min. Individual ii) ) Adhesion of plies.(Knife test)	1350 1100 Min.Pass standard	1690 1510 Excellent
7	Water resistance test (After 72 hrs. boiling), N i) Glue adhesion strength, N a) Average b) Min. Individual ii) Adhesion of plies.(Knife test)	1000 800 Min.Pass standard	1290 1210 Excellent
8	Tensile strength, N/mm2 i) Parallel to the face grain ii) Perpendicular to face grain iii) Sum of the tensile strength	Min. 42.0 Min. 25.0 Min. 84.50	70 60 130
9	Mycological test i) Glue adhesion strength, N a) Average b) Min. Individual ii) Adhesion of plies.(Knife test)	1000 800 Min.Pass standard	1330 1200 Excellent
10	Static bending strength Modulus of Elasticity, N/mm2 i) Along the face grain a) Average b) Min. Individual ii) Across the face grain a) Average b) Min. Individual	7500 6700 4000 3600	9650 9260 8450 7220
11	Modulus of Rupture Modulus of Elasticity, N/mm2 i) Along the face grain a) Average b) Min. Individual ii) Across the face grain a) Average b) Min. Individual	50 45 30 27	82 76 76 74
12	Wet bending strength, Modulus of Elasticity, N/mm2 i) Along the face grain a) Average b) Min. Individual ii) Across the face grain a) Average b) Min. Individual	3750 3400 2000 1800	6860 6340 6150 5750
13	Modulus of Rupture Modulus of Elasticity, N/mm2 i) Along the face grain a) Average b) Min. Individual ii) Across the face grain a) Average b) Min. Individual	25 22 15 13	51 51 46 39
14	Retention of Preservative chemicals, Kg/m3	Min.12	14.650

COMMON THICKNESS RANGE

4mm to 25mm

COMMON SIZE

8feet x 4feet, 7feet x 4feet, 6feet x 4feet, 8feet x 3feet, 7feet x 3feet, 6feet x 3feet, 5feet x 4feet, 5feet x 3feet and other sizes as per customer requirement.

BOND/ADHESIVE

BWP grade resin as per IS 848.
Low formaldehyde formulation for compliance to emission level requirements such as E1.

STANDARD

Conforms to IS 710 (BWP grade)

WARRANTY

Lifetime 700% money back warranty.
