AK GOLD / APPLE
SUMMARY
SPECIALITIES
TECHNICAL INFORMATION
SIZE
AK HIT PLY/APPLE VILLA
SPECIALITIES
State-of-the-art ideas for home and commercial purposes; engineered to deliver the perfect amalgamation of design, durability and performance.
Borer and Powder Free
Klin Seasoned & Uniform Thickness
Low Formaldehyde Emission
Quality Checked
Vaccum Pressure Treated
| NO | TESTS | PRESCRIBED VALUE | VALUE OBTAINED |
| 1 | Dimensions, mm a) Length b) Width c) Thickness |
Tolerance +6mm -0mm Tolerance +3mm -0mm +/-5% |
+1mm +1mm +3% |
| 2 | Squareness, % | 0.2 | 0.06 |
| 3 | Edge straightness, % | 0.2 | 0.06 |
| 4 | Workmanship and Finish | Conforms | Conforms |
| 5 | Moisture Content % | 5-15 | 10 |
| 6 | Resistance to water, Adhesion of plies | Min. Pass standard | Excellent |
| 7 | Modulus of Elasticity, N/mm2 i) Parallel to the face grain a) Average b) Min. Individual ii) Perpendicular to the Face grain a) Average b) Min. Individual |
5000 45002500 2200 |
6450 60805420 5100 |
| 8 | Modulus of Rupture, N/mm2 i) Parallel to the face grain a) Average b) Min. Individual ii) Perpendicular to the Face grain |
40 3620 18 |
60 5445 40 |
COMMON THICKNESS RANGE
4mm to 25mm
COMMON SIZE
8feet x 4feet, 7feet x 4feet, 6feet x 4feet, 8feet x 3feet, 7feet x 3feet, 6feet x 3feet, 5feet x 4feet, 5feet x 3feet and other sizes as per customer requirement.
BOND/ADHESIVE
BWR grade resin as per IS 848.
Low formaldehyde formulation for compliance to emission level requirements such as E1.
STANDARD
Conforms to IS 303 (BWR grade)
WARRANTY
12 years
