MR GRADE
AK HIT PLY/APPLE VILLA
AK ALTRA PLY/ APPLE ALTRA
AK PLY /APPLE CROWN
AK APPLE CROWN
AK Apple Crown Ply is made of high quality hardwood species and is bonded with UMF resin (MR grade). It is manufactured as per IS 303 (MR grade) standards. It has been industrially vacuum pressure treated with approved preservatives to make it borer proof. AK Apple Crown Ply comes with 15 years warranty.
This material is produced as per double pressing technology which includes calibration and re sanding in imported machinery.
AK APPLE CROWN
SPECIALITIES
State-of-the-art ideas for home and commercial purposes; engineered to deliver the perfect amalgamation of design, durability and performance.
TECHNICAL INFORMATION AS PER 303:1989
| SL NO | TEST REPORTS | PRESCRIBED VALUE | RESULTS |
| 1 |
Dimensions, mm a) Length b) Width c) Thickness |
Tolerance +6mm -0mm Tolerance +3mm -0mm +/-5% |
+2mm +1mm +2% |
| 2 | Squareness, % | 0.2 | 0.05 |
| 3 | Edge straightness, % | 0.2 | 0.06 |
| 4 | Workmanship and Finish | Conforms | Conforms |
| 5 | Moisture Content % | 5-15 | 10 |
| 6 | Resistance to water, Adhesion of plies | Min. Pass standard | Pass standard |
| 7 |
Resistance to micro organisms ( Adhesion of plies) |
Min. pass standard |
Excellent |
| 8 |
Modulus of Elasticity, N/mm2 i) Parallel to the face grain a) Average b) Min. Individual ii) Perpendicular to the Face grain a) Average b) Min. Individual |
4000 3600
2000 1800 |
5530 5230
4680 4120 |
| 9 |
Modulus of Rupture, N/mm2 i) Parallel to the Face grain a) Average b) Min. Individual ii) Perpendicular to the Face grain a) Average b) Min Individual |
30 27
15 13 |
52 47
43 36 |
COMMON THICKNESS RANGE
4mm to 25mm
COMMON SIZE
8feet x 4feet, 7feet x 4feet, 6feet x 4feet, 8feet x 3feet, 7feet x 3feet, 6feet x 3feet, 5feet x 4feet, 5feet x 3feet and other sizes as per customer requirement
BOND/ADHESIVE
MR grade resin as per IS 848.
Low formaldehyde formulation for compliance to emission level requirements such as E1.
STANDARD
Conforms to IS 303 (MR grade)
WARRANTY
15 years
